Specifications: Length: 420 Height: 52 Width: 280 {MM}
■ using UHF wireless microphone dedicated band design, from other industrial frequency interference
■ using infrared frequency synchronization technology, simple transmitter operation
■ Using data pilot control technology to effectively prevent the impact of other RF interference and acoustic transmitter switch
■ The transmitter uses two 1.5V / AAA battery-powered, long battery life, easier to maintain
■ with balanced and unbalanced audio outputs for easy connection and a variety of audio equipment
■ a receiver can display the operating parameters of the transmitter, to facilitate monitoring
■ transmitters manufactured using high-strength alloy material, durable
[Packing List: a receiver, two hand-held microphones, two antennas, a master power supply, a manual, two Corner, an audio cable, two non-slip ring, four batteries]
Receiver Technical Parameters:
■ Frequency Range: UHF 500 ~ 900MHz (can be customized frequency)
■ Maximum Deviation: ± 15KHz
■ Letter operating ratio:> 100dB
■ Integrated Distortion: ≤0.02%
■ Frequency stability: ± 0.03%
■ Audio Response: ± 40 Hz-16 KHz
■ Dynamic range:> 100dB
■ Rated current: 480 mA
■ Working temperature: -20 ℃ ~ + 50 ℃
■ Receiver Voltage: DC: 12 ~ 15V
■ Rated current: 150 mA
■ Receiver AC voltage: 100 ~ 240V
Handheld Microphone Technical Parameters:
■ Frequency Range: UHF 500 ~ 900MHz (can be customized frequency)
■ Dynamic range:> 100dB
■ Maximum Deviation: ± 15KHz
■ Letter operating ratio:> 100dB
■ Integrated Distortion: ≤0.02%
■ Frequency stability: ± 0.03%
■ Audio Response: ± 40 Hz-16 KHz
■ Transmit Power: 8.5mW
■ Working temperature: -20 ℃ ~ + 50 ℃
■ Battery life: 10-12 hours
■ Rated current: 150 mA
■ Directivity: uni-directivity
